| cooling way: | |
|---|---|
| Color: | |
| Certifcate: | |
| ETD time: | |
| packing box: | |
| Quantity: | |
HZW-500/10-200
BAILIAN
8414804090
high efficiency mch5 cng compressor filling station refers to a device that pressurizes natural gas through a compressor to a pressure greater than 10 MPa and not greater than 25 MPa, is stored in a high pressure vessel in a gaseous state, or is used for long-distance transportation of natural gas.
The main use of 250bar cng compressor in natural gas filling stations
S/N | ITEMS | TECHNICAL DATA | |
1 | Working medium | CNG GAS | |
2 | model | HZW-500/10-200 | |
3 | Structure | oil free reciprocating Vertical type | |
4 | Pressure stage | 4 | |
5 | Rated capacity(standard)Nm3/h | 500(@inlet pressure 10bar ) | |
6 | Rated inlet pressure MPa(G) | 1.0 | |
7 | Rated outlet pressure MPa(G) | 20 | |
8 | Inlet temperature℃ | ≤45 | |
9 | Outlet temperature ℃ | ≤130 | |
10 | Transmit gas temperature℃ | ≤55 | |
11 | Shaft speed r/min | 300 ※ | |
12 | Cooling way | Water cooling | |
13 | Lubricate way | Shaft and connect rod | Pressure oil lubricate |
Cylinder | Oil free lubricate | ||
14 | Motor power Kw | 90 dIICT4 anti-explosive class ※ | |
15 | Transmit way | Belt driven | |
16 | Installation way | Skid mounted | |
17 | Automatic control parts | Overload ,stop automatic | |
18 | External dimension L×W×H mm | 2500*1700*2350 ※ | |
19 | Inlet and outlet mm | DN50,DN25 | |
20 | Weight Kg | 3800 ※ | |
21 | Voltage | 415v/50hz/3phase | |
22 | Water consumption | 11 T/HR | |
23 | Seal way | Piston rod ,nitrogen filled | |
here is filling station industrial cng compressor technical data:1.The above parameters are for reference only, and subject to the final technical quotation
