WW-2.5/7
BAILIAN
8414804090
The high quality oil free air compressor is now more and more widely used. It is the main body of the air source device. It is a device that converts the mechanical energy of the prime mover (usually an electric motor) into gas pressure energy. It is a compressed air air pressure generating device.
Compressed air quality :oil free low pressure air compressoris the first choice: the oil-free air compressor machine itself does not contain oily materials, which avoids the contamination of the terminal equipment by the oil machine. Therefore, it is necessary to choose the oil-free air compressor to ensure the air quality. . After the air filter unit is installed, it is an ideal gas supply system for the food and pharmaceutical industries.
industrial oil free low pressure air compressor data as follows
MODEL | Capacity (m3min) | Pressure (Mpa) | Speed (r/min) | Noise [db(A)] | Motor (kw) | tank voluem (L) | diemension (L*W*H) | Packing dimension (L*W*H) | N.W | G.W |
WW—2.5/7 | 2.5 | 0.7 | 860 | ≤86 | 2*11 | 330 | 1680*1230*1430 | 1910*1420*1650 | 780 | 930 |
WW—2.5/10 | 2.5 | 1.0 | 770 | ≤86 | 2*11 | 330 | 1680*1230*1430 | 1910*1420*1650 | 780 | 930 |
WW—3.0/7 | 3 | 0.7 | 770 | ≤86 | 2*11 | 330 | 1680*1230*1430 | 1910*1420*1650 | 790 | 940 |
WW—3.0/10 | 3 | 1.0 | 810 | ≤86 | 2*11 | 330 | 1680*1230*1430 | 1910*1420*1650 | 790 | 940 |
WW—3.2/10 | 3.2 | 1.0 | 820 | ≤86 | 2*15 | 330 | 1800*1350*1450 | 1950*1500*1730 | 950 | 1130 |
WW—3.6/10 | 3.6 | 1.0 | 900 | ≤86 | 2*15 | 330 | 1800*1350*1450 | 1950*1500*1730 | 950 | 1130 |
The high quality oil free air compressor is now more and more widely used. It is the main body of the air source device. It is a device that converts the mechanical energy of the prime mover (usually an electric motor) into gas pressure energy. It is a compressed air air pressure generating device.
Compressed air quality :oil free low pressure air compressoris the first choice: the oil-free air compressor machine itself does not contain oily materials, which avoids the contamination of the terminal equipment by the oil machine. Therefore, it is necessary to choose the oil-free air compressor to ensure the air quality. . After the air filter unit is installed, it is an ideal gas supply system for the food and pharmaceutical industries.
industrial oil free low pressure air compressor data as follows
MODEL | Capacity (m3min) | Pressure (Mpa) | Speed (r/min) | Noise [db(A)] | Motor (kw) | tank voluem (L) | diemension (L*W*H) | Packing dimension (L*W*H) | N.W | G.W |
WW—2.5/7 | 2.5 | 0.7 | 860 | ≤86 | 2*11 | 330 | 1680*1230*1430 | 1910*1420*1650 | 780 | 930 |
WW—2.5/10 | 2.5 | 1.0 | 770 | ≤86 | 2*11 | 330 | 1680*1230*1430 | 1910*1420*1650 | 780 | 930 |
WW—3.0/7 | 3 | 0.7 | 770 | ≤86 | 2*11 | 330 | 1680*1230*1430 | 1910*1420*1650 | 790 | 940 |
WW—3.0/10 | 3 | 1.0 | 810 | ≤86 | 2*11 | 330 | 1680*1230*1430 | 1910*1420*1650 | 790 | 940 |
WW—3.2/10 | 3.2 | 1.0 | 820 | ≤86 | 2*15 | 330 | 1800*1350*1450 | 1950*1500*1730 | 950 | 1130 |
WW—3.6/10 | 3.6 | 1.0 | 900 | ≤86 | 2*15 | 330 | 1800*1350*1450 | 1950*1500*1730 | 950 | 1130 |
