OWZ-80/2-12
TECHNICAL DATA | |||||
Medium | O2 | Quantity | 开 备 | ||
Inlet pressure MPa（G） | 0.2 | Inlet temperature ℃ | ≤ 40 | ||
Discharge pressure Mpa（G） | 1.2 | Discharge temperature（after cooling） ℃ | ≤ 50 | ||
Flow rate Nm3/h | 80 | Piston stroke mm | 90 | ||
Model | OWZ-80/2-12 | Compression stages | 1 | ||
Structural style | Fully oil-free lubrication vertical double acting | Cylinder quantity | 2 | ||
Shaft speed r/min | 300 ※ | Voltage V | 380 | ||
Cooling mode | Air cooling | Cooling water flow t/h | --- | ||
Shaft power kw | ≤10.2kw | Main motor speed r/min | 730 | ||
Air inlet and outlet size mm | 25、20 | Water Inlet and outlet size mm | --- | ||
Motor | 15KW 415V 50Hz ※ | ||||
Dimensions mmXmmXmm | 1700*950*1300 ※ | Weight T | 0.86 ※ | ||
Drive mode | Belt drive | ||||
Material of parts in contact with gas | cylinder | Stainless steel | |||
valve | Stainless steel | ||||
Pipeline, cooler | Stainless steel aluminum alloy | ||||
Scope of supply | Main engine, motor, skid mounted chassis, starting cabinet, intake filter, front primary meter and control components, safety valve, random documents, random spare parts, etc. (Note: The final technical agreement shall prevail). | ||||
Additional notes | Reminder: Dangerous gases, users must do a good job in daily security checks! The inlet and exhaust pressure protection automatically starts and stops. Packing seal. | ||||
Delivery time | 40 days after the contract is signed and the advance payment is received | ||||
