GArZ-3/210
Serious reminder: The gas compressed by the compressor must be dry and free of particles!
TECHNICAL DATA | |||||
Medium | Ar | Quantity | 1开 备 | ||
Inlet pressure MPa(G) | Micro positive pressure | Inlet temperature ℃ | ≤ 40 | ||
Discharge pressure Mpa(G) | 21.0 | Discharge temperature(after cooling) ℃ | ≤ 50 | ||
Flow rate Nm3/h | 3 | Piston stroke mm | 40 | ||
Model | GArZ-3/210 | Compression stages | 4 | ||
Structural style | Completely oil-free vertical lubrication | Cylinder quantity | 4 | ||
Shaft speed r/min | 380 ※ | Voltage V | 380 | ||
Cooling mode | Air cooling | Cooling water flow t/h | --- | ||
Shaft power kw | ≤1.6kw | Main motor speed r/min | 970 | ||
inlet and outlet interface mm | 15、M6*1.5 | Water inlet and outlet interfacemm | --- | ||
Motor | 3KW 380V 50Hz ※ | ||||
Dimension mm | 1200X750X1100 ※ | weight T | 0.4 ※ | ||
Drive mode | Belt drive | ||||
Materials in contact with gas | cylinder | carbon steel | |||
Air valve | Stainless steel | ||||
Pipeline and cooler | Stainless steel | ||||
Scope of supply | Main engine, motor, pry mounted chassis, starter cabinet, intake filter, front primary meter and control components, safety valve, random files, random spare parts, etc.(Note: The final technical agreement shall prevail). | ||||
Additional notes | Standard configuration : Electric motor (Luv-electric or Anhui xuanlida or equivalent brand) Safety valve (Zhejiang Wanneng or equivalent brand) solenoid valve(zhejiang Sanlixin)Pressure gauge (Nanjing Zhipu or equivalent brand), pressure controller/pressure transmitter (Changzhou Tianli) Electrical components (Zhengtai) Sealing method: packing sealing. Dual fan heat dissipation | ||||
Delivery time | 50days after the contract is signed and the advance payment is received |
