GZW-20/4-150
Serious reminder: The gas compressed by the compressor must be dry and free of particles!
Medium | N2 99.999% | Quantity | 1开 备 | ||
Inlet pressure MPa（G） | 0.4 | Inlet temperature ℃ | ≤ 40 | ||
Discharge pressure Mpa（G） | 15.0 | Discharge temperature（after cooling） ℃ | ≤ 45 | ||
Flow rate Nm3/h | 20 | Piston stroke mm | 90 | ||
Model | GZW-20/4-150 | Compression stages | 4 | ||
Structural style | Completely oil-free vertical lubrication | Cylinder quantity | 4 | ||
Shaft speed r/min | 170 ※ | Voltage V | 380 | ||
Cooling mode | Air cooling | Cooling water flow t/h | --- | ||
Shaft power kw | ≤8.2kw | Main motor speed r/min | 730 | ||
Air inlet and outlet interface mm | 25、M16X1.5 | Water inlet and outlet interface mm | --- | ||
Motor | 11KW 380V 50Hz ※ | ||||
Dimensions mmXmmXmm | 1600X900X1500 ※ | weight T | 1.0 ※ | ||
Drive mode | Belt drive | ||||
Material of the part in contact with gas | cylinder | Stainless steel | |||
Air valve | Stainless steel | ||||
Pipeline and cooler | Stainless steel, aluminum alloy | ||||
Scope of supply | Main engine, motor, pry mounted chassis, starter cabinet, intake filter, front primary meter and control components, safety valve, random files, random spare parts, etc. (Note: The final technical agreement shall prevail). | ||||
Additional notes | The intake and exhaust pressure protection automatically starts and stops. | ||||
Delivery time | 50 days after the contract is signed and the advance payment is received | ||||
The above parameters are quoted as standard for our company. If there are special requirements, we will discuss them separately.
Easy maintenance: The nitrogen compressor has fewer parts and seals, is easy to maintain and cost effective.
Cost-effective: Nitrogen compressors are characterized by high output power and low cost.
Strong adjustability: The output pressure and flow of the nitrogen compressor are precisely controlled by the pressure regulating valve of the propellant gas.
Adjust the drive air pressure so that the output pressure of the air pressure line booster pump is set exactly between the projecting air pressure and the maximum output pressure.
High output pressure: The maximum working pressure of pneumatic liquid line pressure increase pump can be achieved, and the maximum working pressure of pneumatic gas line pressure increase pump can be achieved.
Excellent material: The high pressure part of the nitrogen compressor is made of hard aluminum alloy. The high-pressure piston is made of stainless steel. And two-layer sealant. The material of the key parts can be selected depending on the medium.
Various gas drives: compressed air, nitrogen, water vapor etc.
Large output current: Pneumatic pipeline booster pump only needs 0.2-0.8 MPa compressed air. All "O" rings of the same pump series, the wear parts of the maintenance kit can be replaced with each other, which significantly reduces maintenance costs. Pneumatic inline booster pumps do not require lubricants.
